Specifications
| G.V.W.R. | 18,000 # | Axles | 2 - 8K Dexter Oil Bath |
| G.A.W.R. (each axle) | 8,000 # | Suspension | Slipper Spring |
| Coupler | Gooseneck | Tires | 215 75R 17.5 |
| Safety Chains | High Tensile Safety Chains | Wheels | 17.5" X 8 |
| Jack | Dual 12K Jacks | Floor | Standard Oak/Treated Pine |
| Neck | 10' I Beam 16# per ft | Lights | LED Lights / DOT Specs. |
| Frame | 10' I Beam 19 # per ft | Finish (prep) | 2 Coats Primer |
| Crossmembers | 3" Channel 16" O.C. | Finish | Paint including underneath |
| Side Rails | 8" Channel | Paint | 2 Coats |
Standard Features
- Rub Rails and Stake Pockets
- Oak / Treated Pine Decking
- Recessed Deck Straps
- Sealed wiring harness
- LED Rubber Mounted Sealed Beam Lights
- 2 year warranty
- Dexter Axles
- 102” Wide
- Slipper Spring Suspension
- Electric Brakes on All Axles
- Radial Tires
- Meets & Exceeds D.O.T. Regulations
- Primed & Painted Underneath
Available Options: On Most Models
- Cargo Winch & Straps
- Additional Deck Length
- Deckover Goose Neck
- Cleated Rear Deck (Tilt)
- Spare Tire & Wheel
- Power Tilt
- Steel Deck
- Any other custom needs
