Specifications
| G.V.W.R. | 14,000 # | Axles | 7K Dexter |
| G.A.W.R. (each axle) | 7,000 # | Suspension | Slipper Spring |
| Coupler | Adjustable Round 2 5/16 | Tires | 235 80R 16 10 Ply |
| Safety Chains | High Tensile Safety Chains | Wheels | 16X6 Lug |
| Jack | 12K Jack | Floor | Standard Oak/Treated Pine |
| Neck | N/A | Lights | LED Lights / DOT Specs. |
| Frame | 10" Channel | Finish (prep) | 2 Coats Primer |
| Crossmembers | 3" Channel 16" O.C. | Finish | Paint including underneath |
| Side Rails | 5" Channel | Paint | 2 Coats |
Standard Features
- Oak / Treated Pine Decking
- Rub Rails and Stake Pockets with Spools
- Recessed Deck Straps
- Sealed Wiring Harness
- LED Rubber Mounted Sealed Beam Lights
- 2 Year Warranty
- Dexter Axles
- 102" Wide
- Slipper Spring Suspension
- Electric Brakes on All Axles
- Radial Tires
- Meets and Exceeds D.O.T. Regulations
- Primed and Painted Underneath
- 5 FT Stand Up Ramps
Available Options: on most models
- Gooseneck Option
- Spring Assist split ramp gate
- Dual Jacks (standard on goosenecks)
- Additional Deck length
- Pop-up Dove Tail
- Wood Filled ramps
- Spare Tire and wheel
- Steel Deck
- Any other custom needs
