Specifications
| G.V.W.R. | 25,000 # | Axles | 10K Dexter Axles |
| G.A.W.R. (each axle) | 10,000 # | Suspension | Heavy Duty Slipper Spring |
| Coupler | 30K Bulldog Adjustable | Tires | 235 80R 16 10 Ply Radials |
| Safety Chains | High Tensile Safety Chains | Wheels | 16" 8 Lug Dual |
| Jack | Dual 12K Drop Leg | Floor | Standard Oak/Treated Pine |
| Neck | 10" I Beam | Lights | LED Lights / DOT Specs. |
| Frame | 10" I Beam | Finish (prep) | 2 Coats Primer |
| Crossmembers | 3" Channel 16" O.C. | Finish | Paint including underneath |
| Side Rails | 6" Channel | Paint | 2 Coats |
Standard Features
- 5' Spring Loaded Ramps
- Oak / Treated Pine Decking
- Rub Rails and Stake Pockets with Spools
- Recessed Deck Straps
- Sealed Wiring Harness
- LED Rubber Mounted Sealed Beam Lights
- 2 year Warranty
- Dexter Axles
- 102" Wide
- Slipper Spring Suspension
- Electric Brakes on All Axles
- Radial Tires
- Meets and Exceeds D.O.T. Regulations
- Primed and Painted Underneath
- Storage in Gooseneck
- Storage with LockingLid
- Dual 12K Jacks
Available Options: on most models
- Air Brakes
- Electric Over Hydraulic Brakes Drum or Disc
- Additional Deck Length
- Pop-up Dove Tail
- Deckover Goose Neck Platform
- Wood Filled Ramps
- Hydraulic Ramps
- Spare Tire and Wheel
- Load Range G Tires Available
- Any other custom needs
